Small but Powerful

Enrange Flex Ex

The Enrange Flex EX series of radio remote controls provides a cost-effective solution to the restrictive use of hardwired pendants.

These durable and rugged radios are ideal for use in material handling, overhead cranes, and industrial applications for single and 2-speed operations. Flexible and reliable, these systems are designed to be ergonomic and lightweight, and are available in 4, 6, 8 and 12 button style options to meet all your application needs.

Download the Brochure for the Flex Ex.

Flexible and Efficient Performance

  • Advanced microprocessor controls with 32 bit CRC and Hamming Code provide ultra-fast, safe, precise and error-free encoding and decoding.
  • Unique I-CHIP design allows information and settings to be transferred between transmitters, increasing flexibility and minimizing spare parts inventory.
  • Flex EX is equipped with more than 200 programmable functions to suit all types of applications.
  • A wide variety of accessories is available to provide additional protection and flexibility, including protective rubber transmitter boots, padded nylon transmitter case, retractable belt clip, and horn kit.
  • Strong and Reliable
  • Reliable pushbuttons feature gold-plated contacts and are rated for more than one million press cycles. The defined snap-action steps provide positive tactile feedback even while wearing gloves.
  • Durable enclosures are made from industrial-strength nylon and fiberglass composite materials.
  • Two “AA” alkaline batteries provide more than 100 hours of operation. A rechargeable battery kit with LED indicators is also available.

Enrange Flex Pro Series Radio Control Systems

The Pro series incorporates both proportional control as well as serial connection to Magnetek’s line of variable frequency drives.

This ergonomically styled Flex Pro series incorporates the latest in proportional control technology in a lightweight, comfortably contoured, yet durable case. It’s available with several options to meet the needs of a variety of applications and industries.

Comfort and Style in One Package

  • Ergonomically designed contoured case with available rubber jacket makes it comfortable for the user.
  • Designed to be compact and lightweight to prevent operator fatigue.

Versatile Yet Precise Operations

  • Choose 8 or 12 proportional button configurations with precise control for smooth operation
  • Adjustable speed control – four mode settings (25%, 50%, 75% and 100% output) provide precise control of machine movement.
  • Buttons can be configured as proportional, on/off, or a combination of both and include a variety of standard labels.
  • Revolutionary I-CHIP module makes this a universal transmitter that can be programmed in the field.

Flexible and Adaptable to Your Specific Requirements
  • Rugged, tough nylon housing is made to withstand shock; protective cases and accessories available for harsh environments.
  • Rated NEMA 4 (IP66); sealed to withstand harsh, industrial environments.
  • Informative LEDs provide diagnostic and system status.
  • Designed to minimize power consumption, providing one of the longest life batteries in the industry today – rechargeable NiMH battery pack available.
  • Custom labeling available.

Flex M Receiver Features
  • Full modular design.
  • Part 15 433MHz.
  • Synthesized RF, 32 channels.
  • Available in 16, 24, 32, 40, 48, and 56 output configurations
  • Stepped control (2, 3, or 5) interfaces available.
  • Stepless (0-5 Vdc, 0-10 Vdc, 0-+/-10 Vdc) interfaces available.

Radio Drive Serial Interface (RDSI) Module

The RDSI module is designed to communicate via a serial interface to directly control Magnetek’s IMPULSE® G+/VG+ Series 4 and IMPULSE® G+ Mini Adjustable Frequency Crane Controls (consult factory for compatibility if you have an existing RDSI setup with a Series 2 drive). The Flex Pro provides one-way communication, contact Engineered Lifting Systems for information on two-way feedback radio combinations available.

The RDSI module:

  • Automatically detects drive types.
  • Eliminates the need for drive contactors.
  • Reduces system costs by eliminating relay cards, excessive wiring and labor.

And don’t forget, the Flex M can be used as a standalone system to eliminate wires and collector rings that transfer control logic.

See our webpage on Enrange products: Enrange Parts.
