Having the opportunity to design, work with, and supply Ace World Companies equipment provides lots of photo opportunities. The following are a view of the Ace machinery applications we have been working with, and might give you a few new ideas:

7-1/2 ton trolley-hoist

These photos are of a 7-1/2 ton trolley-hoist supplied to a Midwest steel distributor. Although the bridges are cab controlled Class D cranes, because of the duty cycle these hoist units are rated at Class E service!

Built-up Ace Design

This photo shows the built-up Ace design. The hoist motor operates at 1200 rpm under 40% or greater load, but with a light or no load condition, these gearboxes operate at 1800 rpm input using Magnetek “Express-Speed”. How about increasing production half the time?

100-ton Ace Built Hoist

This photo shows the built-up Ace design. The hoist motor operates at 1200 rpm under 40% or greater load, but with a light or no load condition these gearboxes operate at 1800 rpm input using Magnetek “Express-Speed”. How about increasing production half the time?

Twin Hook Hoist Trolley Units

The above are pictures (just prior to shipment) of two special twin hook hoist trolley units, each hook rated at 5-tons each (10-tons per hoist), and 12 foot hook centers. Rotating axle design A-4 trolley drive, and that’s an A40 Ace designed and built horizontally split gearbox.

Master Car Builder Bearing Boxes

90 degree Master Car Builder bearing boxes on a bogie endtruck, Class F rated.

50-ton Trolley/Hoist

50-ton trolley/hoist, Class F rated, with wrap-around OSHA service platform.

Low Headroom Hoist

50-ton trolley/hoist, Class F rated, with wrap-around OSHA service platform.

Ace A-75 Gearbox

Ace A-75 gearbox with Mondel Thruster brake.

50 ton Ace Trolley/hoist

We recently installed this 50 ton Ace unit, replacing a P&H Feature-Built trolley/hoist. It features high speed hoist travel and anti-sway reeving.

10-ton Ace Terminator Hoist/Trolley

10-ton Ace Terminator hoist/trolley with Magnetek controls.

For more information about Ace heavy duty cranes, hoists, endtrucks and our crane modernization services please contact Engineered Lifting today.
